The multibase 2072i offers ample room for a comfortable entry and exit.
The MultiBase 2072i is one of the most comfortable parking systems available, since the offset steel pillar allows car doors to be opened further, thus ensuring easy entry and exit. The system accommodates heavy vehicles in a space-saving manner and is perfect for storing vehicles with a height of up to 215 cm. Thanks to the electro-hydraulic synchronization control system, the MultiBase 2072i is more environmentally-friendly, requires less maintenance and is generally more efficient than previous systems with a mechanical synchroniser.
You can also enhance your MultiBase 2072i with our premium accessories.
Specification
√ For independent parking
√ Single platform (SP) for 2 cars or double platform (DP) for 4 cars
√ Total height of standard type: 335 cm
√ Pit depth of standard type: 180/185 cm
√ Vehicle dimensions: height 150 cm up to 215 cm
√ Vehicle dimensions: length 500 cm up to 520 cm
√ Usable platform width (SP): 230 cm up to max 270 cm
√ Usable platform width (DP): 460 cm up to max 540 cm
√ Standard design: 2,000 kg per parking space
√ Optional design: 2,600 kg per parking space
√ Special design: 3,000 kg per parking space - (SP) only
√ Horizontal access to all parking levels
√ Platform coating StandardGrip
√ Platform coating optional AluLongLife or EasyWalk
Product variants :
 |
|---|
Downloads
Field of Application
√ In garages for family homes and apartment buildings
√ In office buildings or residential and commercial buildings
√ In prefabricated garages
√ To increase capacity in underground car parks or
√ To increase capacity in parking garages, e.g. of hotels
√ Can also be used as an outdoor parking system without a garage, e.g. installation in an inner courtyard or a front garden
